Envirotemp® 360 Fluid

Ideally suited for use in free-breathing transformers and other applications like switchgears, Envirotemp 360 synthetic ester fluid provides excellent fire safety and robust performance, even in extreme conditions.

Data Sheet

Your robust, reliable synthetic ester transformer oil

Unlike FR3™ fluid, our superior natural ester dielectric fluid, Envirotemp 360 fluid is perfectly suited for use in free-breathing transformers. Cargill has decades of proven performance with synthetic esters as transformer oil for distribution transformers (pole and pad types), MV/HV power transformers, voltage regulators and OLTCs, rail applications (traction, trackside, and underground), and switchgears.

In addition to its optimized oxidation stability, Envirotemp 360 fluid has a high fire point, excellent thermal and lubricity properties in diverse operating conditions, superior moisture tolerance, and is readily biodegradable (OECD 301B). These physical, chemical, and electrical properties make Envirotemp 360 fluid your solution for a synthetic ester transformer oil that is an alternative to mineral oil and can provide:

Improved fire safety

Extended asset and insulation life

Dielectric strength in extreme temperatures

Better environmental benefits

Envirotemp 360 fluid has been thoroughly evaluated and conforms to IEC 61099 “Specifications for Unused Synthetic Organic Esters for Electrical Purposes.”

DIVIDER

Envirotemp® 360 values and specification units

  Standard test methods ASTM D6871/IEEE C57.147 IEC 62770 FR3 Fluid
Property ASTM ISO/IEC As-received new fluid property requirements Unused new fluid property requirements TYPICAL
Physical
Color D1500 ISO 2211 ≤1.0 - 0.5
Flash Point PMCC (ºC) D93 ISO 2719 - ≥250 260
Flash Point COC (ºC) D92 ISO 2592 ≥275 - 320-330
Fire Point (ºC) D92 ISO 2592 ≥300 >300 350-360
Pour Point (ºC) D97 ISO 3016 <-10 ≤-10 -21
Density at 20ºC (g/cm2) - ISO 3675 - ≤1.0 0.92
Relative Density (Specific Gravity) 15ºC D1298 - ≤0.96 - 0.92
Viscosity (mm2/sec) D445 ISO 3104

100ºC

≤15 ≤15 7.7 - 8.3
40ºC ≤50 ≤50 32 - 34
0ºC ≤500 - 190
Visual Examination D1524 IEC 62770 4.2.1 bright and clear clear, free from sediment and suspended matter clear, light green
Biodegradation OECD 301 readily biodegradable readily biodegradable readily biodegradable
Electrical
Dielectric Breakdown (kV) D877 - ≥30 - 47
Dielectric Breakdown (kV)
1mm gap D1816 - ≥20 - >25
2mm gap D1816 - ≥305 - >50
2.5mm gap - IEC 60156 - ≥35 >50
Dielectric breakdown / impulse, needle/spere, 25C, 25.4mm[kV]
Gassing tendency (mm/min) D2300 - ≤0 - -79
Dissipation Factor
25ºC (%) D924 - ≤0.20 - 0.010 - 0.15
90ºC (tan ∂) - IEC 60247 - ≤0.05 0.02
100ºC(%) D924 - ≤4.0 - 0.41 - 3.85
Chemical
Corrosive Sulfur D1275 IEC 62697 non-corrosive non-corrosive non-corrosive
Water Content (mg/kg) D1533 IEC 60814 ≤200 ≤200 4 - 50
Acid Number (mg KOH/g) D974 IEC 62021.3 ≤0.06 ≤006 0.013 - 0.042
PCB Content (mg/kg) D4059 IEC 61619 not detectable free from PCBs not detectable
Total Additives - IEC 60666   Max weight fraction 5% <2%
Oxidation Stability (48 hrs, 120ºC) - IEC 61125C
Total Acidity (mg KOH/g) - IEC 62621.3   ≤0.6 0.1
Total Acidity (mg KOH/g) - ISO3104   ≤30% increase over initial 17.1%% increase
Dissipation Factor at 90ºC (tan ∂) - IEC 60247   ≤0.5 0.1

Note: Specifications should be written referencing only the defined ASTM or IEC acceptance values and test methods. The listed “typical” values are averaged values summarized from a significant number of data points over many years; they are not to be identified as acceptance values.
ASTM D6871 Standard Specification for Natural (Vegetable Oil) Ester Fluids Used in Electrical Apparatus.
IEC 62770: Fluids for electrochemical applications — Unused natural ester liquids for transformers and similar electrical equipment.
A transformer filled with FR3 fluid complies with the transformer temperature operating ranges requirements defined in IEEE C57.12.00 and IEC 60076-1.

DIVIDER

Envirotemp 360 fluid details

nullHigh flash and fire points

With a flash point of >283°C and a fire point of >315°C, Envirotemp 360 fluid is classified as a Class-K, “less flammable” liquid.

Although its fire point is not as high as that of our natural ester dielectric fluid, FR3 fluid, Envirotemp 360 fluid is still far superior to mineral oil when it comes to fire safety. It is therefore a safer choice than mineral oil for areas where the population density is high, or for enclosed spaces where fire could damage equipment or people.

There have been no pool fires reported in transformers filled with Envirotemp 360 fluid.
